～Automation of Feeding Through Delivery～

The Industry’s first model to move paper back and forth for One-Pass Production of 4 Postcards with Just 1 Plate !

Move Paper back and forth in addition to feeding direction (schematic view)

WITH Automatic Adjustment Function of Paper Size and Head Position
LESS Member! LESS Job ! LESS Plate !

• Highly Cost-Saving
• Management by 1 Member
• Highly Accurate Feeding within±0.5mm
• Fine adjustment to Paper Size and Stamping Position by Touch panel
• Can Do Fine Adjustment to Your Paper Size and Stamping Position with Touch Panel Display
• Can Run Around the Clock
• Applicable to Various Types of Manual Hot Stamping Machine
  • Buy Inexpensive One and Start New Business !
• Just Add Our System to Your Manual Machine

1. The machine in use which can be taken into : conventional hot stamping machine, compressor etc
2. Corresponding size : 100x148~450x600mm
3. Can pile up paper : ～40cm
4. Main Parts list : Robot(MZ-04)，WAVE's standard pedestal，WAVE's original heat-resistent hand，a set of control device，automatic feeder with size and platform-level adjustment function，automatic size and platform level adjustment system，delivery platform
5. Also requires safety curtain (special order product)
6. We also have Less Expensive WAVE15P-002 WITHOUT Size and Stamping Site Adjuster
